WBT WBT-0730.01 Gold Binding Post

Product Description

Price is per binding post (single). When ordered in pairs, you will receive one red, one white, to identify +/-.

Superb mechanical properties, solid design and the two-piece clamping nut with rotatable pressure piece ensure high contact pressure and hence consistently low transition resistance – the precondition for absolutely minimum effect on sound quality. The elegant design of the WBT-0730 binding post is further enhanced by the multi layer gold-plated surface that reliably prevents corrosion.

A 200 ampere continuous current rating makes this connector suitable for all but the most demanding functions.

Outer connection:

• >> 4 mm banana plug
• A 4 mm banana plug can be connected in the front part of the clamping nut.

• >> Spades and crimped cable ends (up to 6 mm²/9 AWG)
• You can use the patented WBT clamping nut system to make high-pressure spade and crimped cable end connections. The cross-milled surface on the bottom of the pressure piece creates a permanently secure connection with extremely low transition resistance. It also prevents the splitting of cable strands if exposed cable ends are used.

Inner connection:

• Cables with a conductor cross section of up to 10 mm² (7 AWG) can be used on the inside.

You can use Torx screws supplied and the Torx T.6 wrench (supplied with every set of 4) to perfectly fix crimped cable ends.
The connections can also be soldered, however. If you decide on soldering, WBT and Krispy recommend the surface-friendly WBT silver solder WBT-0805.

Please note Krispy Audio is the exclusive distributor of WBT products in Australia. We will not sell or supply outside of Australia. We welcome retail enquiry, please contact us for more information.
