Esoteric N-05XE Streamer, dac, pre

N-05XE System Configuration

• D/A Converter: Equipped with a wide range of digital inputs
• Network Streamer: Designed for streaming and music file playback
• Dual-Mono, Dual Balanced Preamplifier
• Dual-Mono, Parallel Single-Ended Headphone Amplifier
• Fully Dual-Mono Construction: All analog and power supply circuits are completely L/R independent

Master Sound Discrete DAC G2

• *Next Generation “G2” DAC: With richer musicality, incorporating the Grandioso N1 technologies
• Highly Advanced Multilevel ΔΣ D/A Converter: Powered by 64-bit/512Fs ΔΣ modulator
• FPGA-Based Discrete Circuit Configuration: Without using an off-the-shelf DAC IC
• Two Independent FPGA Digital Processing Algorithms: Optimised separately for PCM and DSD formats
• *Low-Noise New Register Network: Provides cleaner imaging and lower noise
• High Precision MELF Resistor Elements: Ensures ultra-high D to A conversion accuracy
• Fully Dual-Mono Configuration: Left/right independent analog and power supply circuits
• *“Master Sound Discrete Clock for Digital Player”: Esoteric’s proprietary high-precision clock circuit

ESOTERIC Network Engine G4

• *Next Generation Network Streaming Engine: Supports optical network connections via SFP port
• Dedicated Large Linear Power Supply: Contributes to smooth, vinyl-like, and richly detailed sound
• Native DSD 22.5 MHz Playback Support
• Music Server Function: Supports connection of up to two USB drives
• Wide Range of Supported File Formats: DSF, DSDIFF, FLAC, ALAC, WAV, AIFF, MQA, MP3, AAC
• Esoteric Sound Stream App: Provides extremely comfortable operation on smartphone/tablet
• OpenHome Compliant: Can be controlled using compatible OpenHome applications
• Support for Multiple Streaming Services: Tidal Connect, Qobuz Connect, Roon, Spotify Connect, QQ Music

Dual-Mono, Dual Balanced Preamplifier

• High-Fidelity Dual-Mono, Dual Balanced Circuit: Consists of 8 circuits (L/R, hot/cold independent)
• *Dedicated Attenuator Power Supply: Contributes to pure volume control
• HCLD High-Current Buffer Amplifier: Powerfully drives downstream equipment with no sound quality difference regardless of preamp output, line output, or headphone output
• ES-Link Analog: Esoteric’s proprietary current signal link with amplifier, provides super authentic sound
• *ES-Link Analog input ×1

Dual-Mono, Parallel Single-Ended Headphone Amplifier

• *Completely New Circuit Design: Developed for even higher sound quality
• *Dual-Mono Parallel Single-Ended Amplification: Provides excellent drive capability and control
• 1,200 mW + 1,200 mW Output (32 Ω Load)
• 4-Pin XLR and ¼ (6.3mm) Stereo Phone Headphone Outputs

Other Features

• *Front USB Type-C Port: Functions as a DAC input for smartphones and DAPs
• ES-Link (XLR) Input: Provides digital connectivity to Esoteric SACD transport models
• 10 MHz Clock Input: Enables connection to the G-05 external master clock for further sound quality enhancement
• Bluetooth® Receiver: Supports various high definition codecs; LDAC, LHDC, Qualcomm®aptX ™ HD audio, Qualcomm®aptX ™ audio, AAC, SBC
• Fixed Line Output Mode / Signal Pass-Through Output Mode
• High-Rigidity Chassis Construction: Optimised for effective vibration control
• Semi-Floating Top Panel: Enhances sonic openness and spatial expression
• Patented Pinpoint Isolation Feet: Deliver focused imaging and an open soundstage
• Proudly Made in Tokyo
